Cov Khau Taw Qhia Cov Khau Rau Freight of Elevator THY-GS-02

Cov Khau Taw Qhia Taw Qhia Rau Freight of Elevators THY-GS-02 Featured duab

Lus piav qhia luv luv:

Product Detail

Khoom cim npe

Khoom Parameters

Rated Ceev	≤ 1.0m / s
Rated load	3500kg ib
Positive Force	1850 Nr
Yawing Force	1 450 N
Match Lub Guide Rail	10,16 ib

Cov ntaub ntawv khoom

THY-GS-02 cam khwb cia hlau qhia khau yog haum rau lub tsheb sab ntawm 2 tuj freight of elevator, qhov ntsuas ceev yog tsawg dua los yog sib npaug rau 1.0m / s, thiab cov lus qhia kev sib tw rail dav yog 10mm thiab 16mm. Cov khau taw qhia yog tsim los ntawm cov khau taw qhia lub taub hau, lub taub hau khau lub cev, thiab lub rooj taw qhia khau. Cov khoom siv hlau cam khwb cia ntawm lub rooj zaum khau ua rau lub elevator nqa lub peev xwm muaj zog dua. Nyob rau tib lub sijhawm, cov khau qhia no muaj cov yam ntxwv ntawm kev ruaj ntseg, ua haujlwm ntev thiab kev ua haujlwm siab, uas tuaj yeem txo cov suab nrov thaum lub sijhawm ua haujlwm ntawm lub elevator, txhim kho kev ruaj ntseg, thiab txo qhov yuam kev. Cov kev qhia tsis raug ntawm cov khau thiab phau ntawv qhia kev tsheb ciav hlau, kev sib dhos tsis raug cai, thiab hnav cov khau qhia hauv ob sab phlu, thiab lwm yam yuav ua rau lub tsheb co lossis ua suab nrov, thiab txawm tias cov khau taw qhia yuav poob tawm ntawm txoj kev tsheb ciav hlau.

Teeb meem thiab teeb meem ntawm of the elevator guide shoes

1. Cov khoom txawv teb chaws daig nyob rau hauv cov roj zawj ntawm lub khau raj hauv ob sab phlu yuav tsum tau muab tshem tawm thiab ntxuav hauv lub sijhawm;

2. Cov khau hauv ob sab phlu yog hnav hnyav, ua rau muaj kev sib txhuam ntawm cov hlau npog daim hlau ntawm ob qho kawg thiab cov kev taw qhia rail, thiab yuav tsum tau hloov raws sij hawm;

3. Qhov sib txawv ntawm qhov chaw ua hauj lwm ntawm cov lus qhia ntawm ob sab ntawm lub hoistway yog qhov loj heev, cov kev taw qhia khau yuav tsum tau kho kom muaj qhov sib txawv;

4. Cov khau hauv ob sab hauv hnav tsis sib xws lossis hnav hnyav heev. Cov khau hauv ob sab phlu yuav tsum tau hloov los yog sab hauv ob sab ntawm cov ntxig-hom khau hauv ob sab phlu yuav tsum tau hloov kho, thiab lub caij nplooj ntoos hlav ntawm cov khau qhia yuav tsum tau hloov kho kom cov plaub taw qhia khau sib npaug;
