Sliding Guide khau yog siv rau nruab nrab thiab siab ceev neeg nrog caij elevators THY-GS-310F

Lus piav qhia luv luv:

Product Detail

Khoom cim npe

Khoom Parameters

Rated Ceev	≤ 2.0m / s
Positive Force	1500 Nr
Yawing Force	1 250 N
Match Lub Guide Rail	10,16 ib
Muaj feem xyuam rau lateral capsules

Cov ntaub ntawv khoom

THY-GS-310F zawv zawg high-speed phau ntawv khau kho lub tsheb ntawm cov kev taw qhia rail kom lub tsheb tsuas yog txav mus los. Sab saum toj ntawm cov khau taw qhia yog nruab nrog lub khob roj kom txo cov kev sib txhuam ntawm cov khau hauv ob sab phlu thiab cov kev taw qhia rail. Txhua lub tsheb of the elevator yog nruab nrog plaub txheej ntawm kev taw qhia khau, uas tau nruab rau ntawm ob sab ntawm lub nqaj qaum thiab hauv qab lub rooj zaum hauv qab ntawm lub tsheb; cov kev taw qhia khau ruaj khov ntawm lub tsheb tuaj yeem rov ua dua raws li cov lus qhia ruaj khov ntsia rau ntawm phab ntsa ntawm lub tsev hoistway Lifting zog tiv thaiv lub tsheb ntawm skewing lossis viav vias thaum lub sijhawm ua haujlwm. Kev siv ob lub ntsiab lus zawv zawg kev sib cuag ntawm lub sab sauv thiab qis sliders thiab roj hmab shock-proof pads, ua ke nrog Mitsubishi ib-daim khau hauv ob sab phlu, txo qhov co thaum lub elevator tsheb txav nce thiab nqis, nrog kev ruaj ntseg zoo thiab xis nyob. Feem ntau yog siv rau cov elevator uas nws ntsuas ceev qis dua 2.0m / s.

Qhia khau kho txoj kev

(1) Kho plaub hau, uas yog, kho qhov sib txawv X1, coj X1 = 1 ~ 2mm.

(2) Tighten lub txiv ntseej kho kom haum qhov sib txawv rau tus nqi tsim nyog. Qhov sib txawv tuaj yeem txiav txim siab raws li kev thauj khoom. Rau kev thauj khoom> 1000kg, nws tuaj yeem yog 2.0 ~ 2.5mm; rau ib qho load ≤ 1000kg, nws tuaj yeem yog 4 ~ 4.5mm.

(3) Tom qab txhim kho cov khau qhia, rov qab kho cov txiv ntoo los ntawm ib nrab tig. Tom qab hloov kho, zawm lub ntsuas phoo.

FAQS

Koj lub tuam txhab cov khoom lag luam yog dab tsi?

Torindrive, Monadrive, Montanari, Faxi, Sylg, Xinda, Kds, Xizi, Nbsl, Ouling, Bst, Flying, Hd, Eshine, Fermator, Dongfang, Huning, Aodepu, Wittur, Marazzi, Rlb, Feinai, Weco, gustav, Goldsun, Langshan.

Koj lub tuam txhab kev tsim khoom yog dab tsi?

Daim phiaj xwm kev muag khoom tso tawm → Elevator civil thiab technical processing → Production department tau txais cov lus qhia los kho cov phiaj xwm → Kev tsim tawm cov ntawv ua tiav → Cov lus qhia ntim → Tshaj tawm cov khoom siv raw thiab cov khoom siv thiab cov khoom ntim khaws cov npe → Npaj ntau lawm → Cov txheej txheem kev tsim khoom, kev saib xyuas zoo → Kev txhim kho kev txhim kho → Thov kev tshuaj xyuas → Kev tshuaj xyuas → Cov ntaub ntawv pov tseg

Koj lub tuam txhab cov khoom lag luam ib txwm siv sijhawm ntev npaum li cas?

Lub sijhawm xa khoom ntawm lub elevator ua tiav yog 20 hnub ua haujlwm, thiab lub tsev yog li 15 hnub ua haujlwm. Peb yuav npaj cov khoom xa tuaj sai li sai tau rau lwm qhov raws li cov lus qhia tshwj xeeb, kom muaj nuj nqis thiab kev xa khoom ntawm kev txiav txim tshwj xeeb. Yog xav paub ntxiv, thov hu rau peb ua ntej xaj.
